DESIGN OF A LIFTER FOR HORIZONTAL CHAMBER MACHINE IN A LEAF SPRING PRODUCTION LINE: A CASE STUDY AT PT. XYZ
DOI:
https://doi.org/10.26740/otopro.v21n2.p69-77Keywords:
Finite Element Analysis, Lifter Frame Design, Structural Strength Analysis, Safety Factor, Fatigue LifeAbstract
PT. XYZ is an automotive manufacturing company that produces leaf springs. One of the machines used in the leaf spring forming process is a Horizontal Chamber Machine that works by pressing. In its operation, this machine requires a lifter to assist in the transfer of leaf springs and reduce the risk of workplace accidents. The lifter has a frame component that functions as the main structure in supporting the load during the lifting and lowering of the leaf spring. Therefore, it is necessary to design a lifter frame that is safe and capable of withstanding the working load that occurs during the production process. This study aims to design and evaluate the strength of the lifter frame to ensure its safety in operational use. There are three variations of frame designs differentiated by material thickness, namely 10 mm, 12 mm, and 14 mm. The simulation results show that the maximum stress in frame design 1 is 24 MPa, frame design 2 is 16 MPa, and frame design 3 is 12 MPa. The strain values for each design are 0.000066, 0.000048, and 0.000036, while the displacement maximum values are 0.026 mm, 0.016 mm, and 0.016 mm. The safety factors obtained are 11, 15, and 19, respectively. The fatigue life value for all frame designs is cycles. Based on these simulation results, frame design 1 is declared to have met the strength and safety criteria required for use in the production process
References
A. R. A. Ramadhan, A. Muchlis, and P. A. T. Fajar, ‘Manufaktur Handle Lifter Dengan Material SS400’, vol. 3, p. 12, 2025.
A. Seidakhmet et al., ‘Research of Kinematics and Dynamics of the Lever Lifting Mechanism Used in the Mobile Automotive Lift’, Applied Sciences (Switzerland), vol. 13, no. 20, 2023, doi: 10.3390/app132011361.
R. Balaji, C. P. Dhondiram, B. A. Chandrakant, and S. P. Namdev, ‘Pneumatic scissor lift’, vol. 11, no. 3, pp. 3–6, 2025.
Y. A. Purwoko et al., ‘Perancangan dan Implementasi Lifter pada Proses Pemasangan Tangki Bensin untuk Mengurangi Keluhan Muskuloskeletal Design and Implementation of a Lifter in the Fuel Tank Installation Process to Reduce Musculoskeletal Complaints’, vol. 6, no. 2, pp. 706–720, 2025.
Y. A. Rahmawati, ‘Penerapan Alat Bantu Lifter Bridge Untuk Mengurangi Waktu Dan Jarak Tempuh Dalam Pemindahan Barang Setengah Jadi Di Pt. Tmmin’, Jurnal Teknika, vol. 13, no. 2, p. 77, 2021, doi: 10.30736/jt.v13i2.659.
M. A. Ficki et al., ‘MENGGUNAKAN PERANGKAT LUNAK One of the main components in the rice husk grinding machine is the frame . The frame is the most important fundamental part , especially for use in machinery , because the function of the frame is as a support for the componen’, vol. 15, no. November, 2022.
S. A. Pratam, Syarifuddin, and A. Suprihadi, ‘Pembuatan Rangka Mesin Pelet Ikan 3 in 1’, Journal Mechanical Engineering (NJME), vol. X, no. X, p. 2, 2021.
T. W. Setiawan and Y. Y. Kristiawan, ‘Pengerasan Permukaan Baja Karbon Rendah Dengan Metode Thermal Spray Coating’, Jurnal Teknika, vol. 6, no. 4, pp. 185–194, 2020.
C. Tabayyun, Kardiman, and Ujiburrahman, ‘Analisis Frame Meja Dandori Menggunakan Metode Finite Element Analysis (FEA)’, Metrotech (Journal of Mechanical and Electrical Technology), vol. 4, no. 2, pp. 77–87, 2025, doi: 10.70609/metrotech.v4i2.6955.
A. Toteles and F. Alhaffis, ‘ANALISIS MATERIAL KONTRUKSI CHASIS MOBIL LISTRIK LAKSAMANA V2 MENGGUNAKAN SOFTWARE AUTODESK INVENTOR Program Studi Sarjana Terapan Teknik Mesin Produksi dan Perawatan , Jurusan Teknik Mesin , Politeknik Negeri Bengkalis Email : arishtoteles99@gmail.com 30’, Machine; Jurnal Teknik Mesin, vol. 7, no. 1, pp. 30–37, 2021.
H. Sandalcılar, ‘Structural Optimization of a Formula Student Upright Using the BESO Method : Enhancing Performance Through Lightweight Design’, vol. 9, pp. 536–546, 2025.
A. E. Ismail and A. K. Ariffin, ‘Fatigue assessment of an existing steel bridge by finite element modelling and field measurements’.
A. Atmawijaya, E. Sofyan, F. Setiawan, and M. K. Adam, ‘Analisis dan Desain Wing UAV VTOL Menggunakan Finite Element Analysis’, Teknika STTKD : Jurnal Teknik, Elektronik, Engine, vol. 9, no. 1, pp. 144–151, 2023.
H. Zhang, T. Gao, J. Chen, X. Li, H. Song, and G. Huang, ‘Investigation on Strain Hardening and Failure in Notched Tension Specimens of Cold Rolled Ti6Al4V Titanium Alloy’, Materials, vol. 15, no. 10, 2022, doi: 10.3390/ma15103429.
H. L. Wijayanto, Zulfianti, Yusdianto, H. A. R. S, and Usman, ‘Design and Safety Factor Simulation of an Automated Feeder for Blanking Machines’, Media Mesin: Majalah Teknik Mesin, vol. 26, no. 2, pp. 98–111, 2025, doi: 10.23917/mesin.v26i2.6977.
R. S. Khurmi and J. K. Gupta, A Textbook of Machine Design. New Delhi: S Chand And Com an Limited, 2004.
R. Motte and W. De Waele, ‘An Overview of Estimations for the High-Cycle Fatigue Strength of Conventionally Manufactured Steels Based on Other Mechanical Properties’, Metals (Basel)., vol. 14, no. 1, 2024, doi: 10.3390/met14010085.
MatWeb. (2024). Material Property Data: SS41 Structural Steel. Available at: https://www.matweb.com
